Hytera HP565
Walkie Talkies

Hytera HP565

Professional DMR Portable Two-Way Radio

Contact for Price
Minimum Order Quantity:10 units

The Hytera HP5 Series is a new-gen professional portable two-way radio that provides reliable voice communications for high-end office buildings, stadiums, industrial parks, schools, hospitals, and more. Effortless usability is reengineered with two dedicated knobs for volume and channel controls, improving your efficiency. The universal Type-C port makes programming, upgrading, and charging more convenient than ever before. The BT 5.2 capability gives you more mobility you need to get the job done, without the hassle of wires and cords. Reliability is redefined - durable enough to withstand dust, heat, shock and water submersion, the HP5 Series is IP67 and MIL-STD-810H certified.

IP67 Waterproof
MIL-STD-810H
ETSI DMR Compliant
Bluetooth 5.2
GPS/GLONASS (Optional)
AES128/AES256 Encryption

Key Features

Crisp Clear Audio

AI-based noise cancellation purifies your voice and eliminates noise. Advanced technology suppresses feedback howling and filters out unwanted ambient noises for face-to-face conversation quality.

Break Through Distance

Exceptional 0.18uV sensitivity provides outstanding communication coverage. Ensures reliable communications even at the far edge of coverage with weak signal.

Versatile Type-C Port

Universal USB Type-C port allows sharing cables with smartphones. Charge with power bank or car charger, program and upgrade conveniently.

Bluetooth 5.2

Optional BT 5.2 enables wireless connection with audio accessories for total freedom without cords. Pair with smartphone for radio programming via HyTool Radio Manager app.

Location Tracking

Optional GPS and GLONASS positioning systems provide real-time location updates. Dispatcher can receive radio location automatically sent with emergency call for quick assistance.

Rugged Reliability

IP67-rated and MIL-STD-810H certified. Polycarbonate housing with excellent abrasion and heat resistance. Non-slip texture on back. Withstands dust, water, vibrations, 1.5m drops, extreme temperatures.

Technical Specifications

Frequency RangeUHF: 400-470 MHz / VHF: 136-174 MHz
Channel CapacityHP50X: 256 / HP56X: 512 channels
Zone CapacityHP50X: 16 / HP56X: 32 zones
Zone ChannelsHP50X: 16 / HP56X: 32 channels per zone
Channel Spacing12.5 kHz / 20 kHz / 25 kHz
Operating Voltage7.4V (rated)
Battery1500 mAh Li-ion
Battery Life (5/5/90)15h (GNSS OFF) / 13h (GNSS ON)
Frequency Stability±0.5 ppm
Antenna Impedance50Ω
Dimensions (H x W x D)119 x 55 x 30.5 mm
Weight (with antenna & battery)HP50X: 265g / HP56X: 270g
DisplayHP50X: None / HP56X: 1.45 inch LCD, 240 x 320 pixels, colorful
BluetoothBT 5.2 BLE+EDR
Receiver Sensitivity (Analog)0.18uV (12dB SINAD) / 0.16uV typical
Receiver Sensitivity (Digital)0.18uV (BER 5%)
Adjacent Channel Selectivity60dB@12.5kHz / 70dB@20/25kHz (TIA-603)
Intermodulation70dB@12.5/20/25kHz (TIA-603)
Spurious Response Rejection70dB@12.5/20/25kHz
Blocking80dB (TIA-603) / 84dB (ETSI)
Rated Audio Power Output0.5W
Rated Audio Distortion≤3%
RF Power OutputUHF: 1W/4W / VHF: 1W/5W
FM Modulation11KOF3E@12.5kHz / 14KOF3E@20kHz / 16KOF3E@25kHz
4FSK Digital Modulation7K60FXD (Data only) / 7K60FXW (Data & Voice)
Digital Vocoder TypeAMBE+2 / SELP
Operating Temperature-30°C to +60°C
Storage Temperature-40°C to +85°C
ESD ProtectionIEC 61000-4-2 Level 4: ±8kV (contact) / ±15kV (air)
Dustproof & WaterproofIEC 60529 - IP67
HumidityPer MIL-STD-810H
Shock and VibrationPer MIL-STD-810H
GNSSGPS, GLONASS, GPS+GLONASS
TTFF Cold Start<1 minute
TTFF Hot Start<10 seconds
Horizontal Accuracy<5 meters
