Motorola DP3661e
Walkie Talkies

Motorola DP3661e

MOTOTRBO Digital Two-Way Radio with Display

Contact for Price
Minimum Order Quantity:10 units

The MOTOTRBO DP3661e is an advanced digital two-way radio featuring a color display and comprehensive connectivity options including Bluetooth, Wi-Fi, and integrated GNSS/GPS positioning. With IP68 waterproof and dustproof rating, MIL-STD 810 rugged performance, and enhanced audio quality, the DP3661e delivers reliable communication in the most demanding environments. The intuitive display screen provides visual channel information and menu navigation, while the ergonomic design ensures comfortable operation during extended shifts. Ideal for mission-critical communications across public safety, industrial, and commercial sectors.

IP68 Waterproof (2m for 4hrs)
MIL-STD 810 C/D/E/F/G/H
ETSI DMR Compliant
Bluetooth 4.0
Wi-Fi 802.11b/g/n
GNSS (GPS/GLONASS/Galileo)
TIA4950 HazLoc Certified
FCC Part 90
IC RSS-119

Key Features

Color Display

Clear color display provides visual channel information, menu navigation, and status indicators. Easy-to-read screen enables quick access to settings and features with intuitive icon-based interface.

Advanced Wireless Connectivity

Integrated Bluetooth enables wireless audio accessories and data transfer. Wi-Fi connectivity supports remote management and firmware updates. Built-in GNSS/GPS provides precise location tracking for workforce management.

Superior Ruggedness

IP68 rated for complete waterproof and dustproof protection (submersible up to 2m for 4 hours). MIL-STD 810 certified for shock, vibration, and extreme temperature resistance. Built to withstand the harshest working environments.

Enhanced Audio Quality

Advanced audio processing delivers loud, clear speech even in high-noise environments. Intelligent noise cancellation filters background interference. Optimized speaker design maximizes audio output.

Smart Battery Management

IMPRES smart battery technology optimizes charging cycles and extends battery life. Intelligent power management maximizes operational time. Up to 24 hours of continuous use on a single charge.

Technical Specifications

Frequency RangeVHF: 136-174 MHz / UHF: 400-470 MHz / 350-390 MHz
Channel Capacity1000 channels
Power Output5W (VHF/UHF), 4W (350MHz)
Battery Life (Li-Ion 2900mAh)24.0 hours digital / 18.0 hours analog
DisplayColor LCD with backlight
KeypadNavigation keys + P1/P2 programmable buttons
Protection RatingIP68 (submersible 2m for 4hrs)
Military StandardMIL-STD 810 C/D/E/F/G/H
BluetoothVersion 4.0, 10m range
Wi-FiIEEE 802.11b/g/n, WPA/WPA2 security
GNSSGPS, GLONASS, Galileo, <5m accuracy
Audio ResponseTIA603D compliant
Modulation4FSK Digital, 12.5/20/25 kHz
Digital ProtocolETSI TS 102 361-1,-2,-3 DMR Tier II & III
Dimensions (H x W x D)130 x 55 x 43 mm (with 2900mAh battery)
Weight365g (with 2900mAh battery)
Operating Temperature-30°C to +60°C
Channel Spacing12.5/20/25 kHz
Receiver Sensitivity (Digital)0.22 μV (BER 5%)
Receiver Sensitivity (Analog)0.22 μV typical (12dB SINAD)
Adjacent Channel Selectivity60/70/70 dB @ 12.5/20/25 kHz
Audio Output Power0.5W nominal, <5% distortion
Frequency Stability±0.5 ppm (-30°C to +60°C)
Antenna Impedance50Ω
IMPRES SupportYes (smart battery technology)
Programmable ButtonsP1, P2 + navigation keys
Emergency FeaturesOne-touch emergency button, man-down, lone worker
Voice FeaturesVOX, voice scrambler (optional), talkaround
