Motorola DM4601e
Mobile Radios

Motorola DM4601e

MOTOTRBO Digital Mobile Radio with Display

Contact for Price
Minimum Order Quantity:5 units

The MOTOTRBO DM4601e is a premium digital mobile radio featuring an integrated color display for enhanced user experience. Delivering 40W of reliable RF output power, it combines DMR Tier II technology with intuitive visual interface for superior communication control. The color display provides clear channel information, menu navigation, and status indicators, while Bluetooth connectivity enables wireless audio accessories. With GPS readiness and robust construction, the DM4601e is ideal for fleet management, public safety, and commercial transportation applications requiring advanced mobile communication capabilities.

CE Certified
FCC Part 90
ETSI DMR Compliant
RoHS Compliant
IP54 Rated

Key Features

Color Display

Integrated color LCD provides intuitive visual interface for channel information, menu navigation, and status monitoring. Easy-to-read display enhances operational efficiency and user experience.

Powerful Output

40W RF output power ensures extensive coverage area for vehicle-mounted operations. Adjustable power settings optimize performance and battery consumption for different scenarios.

Digital Efficiency

DMR Tier II technology doubles spectrum capacity compared to analog systems. Superior audio quality with advanced noise cancellation delivers clear communication in noisy environments.

Connected & GPS Ready

Integrated Bluetooth supports wireless audio accessories and hands-free operation. GPS-ready design enables location tracking and dispatch capabilities for fleet management applications.

Technical Specifications

Frequency Range136-174 MHz (VHF) / 403-470 MHz (UHF)
Channel Capacity160 channels
RF Output Power25-40W (adjustable)
Power Supply13.2V DC (nominal), 10.8-15.6V DC (operating range)
Current Consumption (Standby)≤ 0.6A
Current Consumption (Full Load)≤ 10A @ 40W
Operating Temperature-30°C to +60°C (-22°F to +140°F)
Storage Temperature-40°C to +85°C (-40°F to +185°F)
Humidity5% to 95% RH, non-condensing
Dimensions (H x W x D)52 x 170 x 165 mm (without brackets)
Weight1.35 kg
Receiver Sensitivity (Analog)0.22 μV typical (12 dB SINAD)
Receiver Sensitivity (Digital)0.22 μV typical (BER 5%)
Adjacent Channel Selectivity≥70dB @ 12.5kHz / ≥80dB @ 20/25kHz
Intermodulation Suppression≥65dB typical
Spurious & Harmonics≤ -70dBc (≤ 1W), ≤ -60dBc (> 1W)
Audio ResponseTIA603D compliant, ±1.5dB
Audio Distortion≤3% typical
Modulation4FSK Digital, 12.5/20/25 kHz
Digital ProtocolETSI TS 102 361-1,-2,-3 DMR Tier II & III
DisplayColor LCD with backlight, 1.45 inch
Programmable Buttons5 buttons (P1-P4 + Home/Back)
Navigation KeysUp/Down/OK keys for menu navigation
BluetoothVersion 2.1 + EDR, Class 2
GPSOptional integrated GPS receiver, NMEA 0183 output
ConnectivityAntenna (SO-239), Power/Mic (8-pin DIN), Accessory (DB9)
