Hytera BD505
Walkie Talkies

Hytera BD505

DMR Handheld Radio

Contact for Price
Minimum Order Quantity:10 units

The Hytera BD505 is a DMR handheld radio that represents a new device class for entering digital technology. Offering functions comparable to simple analog radios in the same price class, the BD505 delivers better performance with the advantages of digital transmission technology. With excellent reception properties, robust construction, and clear voice quality, this radio ensures trouble-free voice communication even over large distances. Developed and tested in compliance with MIL-STD-810 G and IP54 standards, the BD505 is built to withstand demanding environments while providing reliable performance.

IP54 Rated
MIL-STD-810 G
ETSI DMR Tier II Compliant
IEC 61000-4-2 ESD Level 4
XPT Digital Trunking Support
Simulcast Support

Key Features

Getting Started Easily

The BD series offers functions comparable to simple analog radios but with the advantages of digital transmission technology. Perfect entry point into DMR digital communications with intuitive operation.

Excellent Performance

Better performance than analog radios with excellent reception properties. Ensures trouble-free voice communication with superior signal clarity even at the edge of coverage.

Robust and Durable

Developed and tested in compliance with MIL-STD-810 G. IP54 dust and water-proof construction ensures reliability in different environments and harsh conditions.

Clear Voice Quality

Digital coding and correction technology transmits voices without interference. Clear audio quality maintained even over large distances with noise cancellation.

Simple Operation

Ergonomically optimized volume keys ensure easy operation, even while wearing gloves. Intuitive controls designed for efficient use in any situation.

Technical Specifications

Frequency RangeVHF: 136-174 MHz / UHF: 400-470 MHz
Supported Operating ModesDMR Tier II (ETSI TS 102 361-1/2/3), Simulcast, XPT Digital Trunking, Analog
Channel Capacity48 channels
Zone Capacity3 zones
Channel Spacing12.5 kHz (analog) / 12.5 kHz (digital)
Operating Voltage7.2V
Standard Battery1500 mAh Li-ion (optional 2000 mAh)
Battery Life (Analog, 5/5/90)Approx. 12 hours (1500 mAh)
Battery Life (Digital, 5/5/90)Approx. 12 hours (1500 mAh) / 16 hours (2000 mAh)
Frequency Stability±0.5 ppm
Antenna Impedance50Ω
Dimensions (H × W × D)108 × 54 × 29 mm
Weight (with antenna & battery)Approx. 220g
Operating Temperature-30°C to +60°C
Storage Temperature-40°C to +85°C
ESD ProtectionIEC 61000-4-2 Level 4: ±8kV (contact) / ±15kV (air)
Dust and Water ProtectionIP54
Shock and Vibration ResistanceMIL-STD-810 G
Transmit Power (VHF)1W / 5W
Transmit Power (UHF)1W / 4W
Modulation (Analog)11K0F3E @ 12.5 kHz / 16K0F3E @ 25 kHz
Modulation (Digital)7K60FXD (data only) / 7K60FXW (data & voice) @ 12.5 kHz
Digital Vocoder TypeAMBE+2™
Receiver Sensitivity (Analog)0.22 μV typical (12 dB SINAD) / 0.4 μV (20 dB SINAD)
Receiver Sensitivity (Digital)0.22 μV (BER 5%)
Adjacent Channel Selectivity (TIA-603)60 dB @ 12.5 kHz / 70 dB @ 25 kHz
Intermodulation65 dB @ 12.5/25 kHz
Spurious Response Rejection70 dB @ 12.5/25 kHz
Signal-to-Noise Ratio40 dB @ 12.5 kHz / 45 dB @ 25 kHz
Audio Distortion≤3%
Nominal Audio Power Output0.5W
