Walkie Talkies

Hytera BP565

Enhanced Business Two-Way Radio

Contact for Price

Minimum Order Quantity:10 units

The Hytera BP565 is an enhanced business two-way radio from the BP51X/BP56X series, designed for professional communication in demanding environments. Featuring a 1.77-inch TFT color display, 128-channel capacity, and Type-C charging interface, it delivers reliable digital communication with exceptional ease of use. With IP54 protection rating and MIL-STD-810G compliance, the BP565 ensures robust performance in harsh conditions. The intelligent noise cancellation algorithm and 3W high-power speaker provide crystal-clear audio even in noisy industrial environments.

IP54 Rated

MIL-STD-810G

ETSI DMR Tier II Compliant

CE Certified

Type-C Charging

Bluetooth 5.0 (Optional)

Download Datasheet (PDF)

Key Features

Clear Display

1.77-inch TFT color display provides clear visibility of channel information, signal strength, and battery status. Intuitive menu navigation with dedicated navigation keys for efficient operation.

Extended Battery Life

1500mAh standard Li-ion battery delivers up to 16 hours (digital) / 12 hours (analog) of operation. Optional 2000mAh battery extends usage to 21 hours (digital) / 16 hours (analog) for full-shift reliability.

Rugged & Reliable

IP54 dust and water-proof construction protects against harsh environments. MIL-STD-810G tested for shock, vibration, and extreme temperature resistance from -30°C to +60°C.

Superior Audio Quality

3W high-power speaker delivers 90dBA maximum volume. Intelligent three-level noise cancellation algorithm filters out background noise for clear voice transmission.

Technical Specifications

Product SeriesBP51X / BP56X Enhanced Business Two-Way Radio

ModelBP565 (BP56X with display)

Frequency RangeUHF: 400-470 MHz / VHF: 136-174 MHz

Channel Capacity128 channels (BP56X) / 64 channels (BP51X)

Zone Capacity8 zones (BP56X) / 4 zones (BP51X), 16 channels per zone

Channel Spacing12.5 kHz / 20 kHz / 25 kHz

Operating Voltage7.4V (nominal)

Battery Type1500mAh Li-ion (standard) / 2000mAh Li-ion (optional)

Battery Life (Analog, 5-5-90)12h (1500mAh) / 16h (2000mAh)

Battery Life (Digital, 5-5-90)16h (1500mAh) / 21h (2000mAh)

Display1.77-inch TFT color screen (BP56X only)

KeypadNavigation keys + P1/P2/P3 programmable buttons

Protection RatingIP54 (dust and water-proof)

Military StandardMIL-STD-810 G

BluetoothBT 5.0 BLE+EDR (optional)

RF Power OutputVHF: 5W/1W (adjustable) / UHF: 4W/1W (adjustable)

Audio Output Power1W (rated), 90dBA max volume

Modulation4FSK Digital (12.5kHz), DMR Tier II compliant

Digital ProtocolETSI TS 102 361-1/2/3 DMR Tier II

Receiver Sensitivity (Analog)≤0.25 μV (12dB SINAD)

Receiver Sensitivity (Digital)≤0.25 μV (BER 5%)

Adjacent Channel Selectivity≥60dB @ 12.5kHz / ≥70dB @ 20/25kHz

Dimensions (H x W x D)115 x 55 x 29.5 mm

Weight230g (BP56X with antenna and 1500mAh battery)

Operating Temperature-30°C* to +60°C (*Host unit only, battery: -20°C)

Storage Temperature-40°C to +85°C

Frequency Stability±0.5 ppm

Antenna Impedance50Ω

Charging InterfaceType-C USB charging port

Programmable ButtonsP1, P2, P3 + navigation keys

Noise CancellationIntelligent three-level adjustable noise reduction

Emergency FeaturesEmergency alarm, emergency call, lone worker
