Motorola R5 NKP
Walkie Talkies

Motorola R5 NKP

MOTOTRBO R5 Non-Keypad Portable Radio

Contact for Price
Minimum Order Quantity:10 units

The MOTOTRBO R5 Non-Keypad (NKP) is a professional portable two-way radio featuring advanced digital technology without keypad interface for streamlined operation. With 64 channel capacity, IP67 protection, and MIL-STD-810H compliance, the R5 NKP delivers reliable performance in demanding environments. AI-powered noise cancellation and SINC+ technology ensure intelligible communication in the noisiest conditions. The sleek ergonomic form factor and intuitive controls enable confident one-handed operation for workers who need to focus on their tasks.

IP67 Rated
MIL-STD-810H
TIA4950 Hazloc
ETSI DMR Tier II Compliant
FCC Certified
IC Certified
Maritime Certified (UHF models)
Download Datasheet (PDF)

Key Features

Advanced Digital Technology

TDMA dual-slot technology doubles channel capacity within 12.5 kHz bandwidth. 64 channel capacity across 4 zones supports efficient deployment. DMR Tier II compliant with backward analog compatibility for smooth migration.

Superior Audio Quality

AI-trained noise suppression and SINC+ noise cancellation filter background interference. Intelligent audio with automatic acoustic feedback suppression eliminates whistling. Maximum loudness of 106 phons ensures intelligible communication in extreme noise.

Rugged Construction

IP67 rated protection against dust immersion and water submersion. Built to MIL-STD-810H standards for shock, vibration, and extreme temperature resistance. TIA4950 Hazloc certified for hazardous location operation.

Extended Battery Life

Multiple battery options: 2200mAh (21.5hrs digital/16hrs analog), 2400mAh (24hrs digital/18hrs analog), or 3200mAh (32hrs digital/24hrs analog). IMPRES smart battery management optimizes charging cycles.

Ergonomic Design

Sleek compact form factor fits naturally in hand for extended use. Intuitive button layout with 3 programmable buttons enables quick access to frequently used functions. No-display design simplifies operation for focused work.

Safety Features

Emergency button, lone worker, and remote monitor features protect personnel in hazardous environments. Transmit interrupt enables priority communications. Radio disable/enable for fleet management security.

Technical Specifications

Product SeriesMOTOTRBO R5 Series Portable Radios
ModelR5 NKP - Non-Keypad Model
Frequency RangeVHF: 136-174 MHz / UHF: 400-527 MHz
Channel Capacity64 channels (NKP variant)
Zone Capacity4 zones (4 channels per zone)
Channel Spacing12.5 / 20.0 / 25.0 kHz
Operating Voltage7.5V DC (nominal)
Battery Options2200mAh / 2400mAh / 3200mAh Li-ion IP67
Battery Life (2200mAh, Digital)21.5 hours (5/5/90 duty cycle)
Battery Life (2200mAh, Analog)16 hours (5/5/90 duty cycle)
Battery Life (2400mAh, Digital)24 hours (5/5/90 duty cycle)
Battery Life (2400mAh, Analog)18 hours (5/5/90 duty cycle)
Battery Life (3200mAh, Digital)32 hours (5/5/90 duty cycle)
Battery Life (3200mAh, Analog)24 hours (5/5/90 duty cycle)
Dimensions (2200mAh)122 x 56 x 35 mm
Dimensions (2400mAh)122 x 56 x 41 mm
Dimensions (3200mAh)122 x 56 x 41 mm
Weight (2200mAh)269g without antenna
Weight (2400mAh)297g without antenna
Weight (3200mAh)301g without antenna
DisplayNone (NKP non-keypad variant)
Programmable Buttons3 programmable buttons (including emergency)
Protection RatingIP67 (submersible 1m for 30 min)
Military StandardMIL-STD-810H
Hazloc CertificationTIA4950 Hazloc
Operating Temperature-30°C to +60°C (-22°F to +140°F)
Storage Temperature-40°C to +85°C (-40°F to +185°F)
Frequency Stability±0.5 ppm
Antenna Impedance50Ω
RF Power Output (VHF High)5W
RF Power Output (VHF Low)1W
RF Power Output (UHF High)4W
RF Power Output (UHF Low)1W
Modulation (Analog 12.5kHz)11K0F3E
Modulation (Analog 25kHz)16K0F3E
Modulation (Digital 12.5kHz Data)7K60F1D / 7K60FXD
Modulation (Digital 12.5kHz Voice)7K60F1E / 7K60FXE
Digital ProtocolETSI TS 102 361-1/-2/-3 DMR Tier II
Digital VocoderAMBE+2
Conducted Spurious Emission<-36 dBm (<1GHz) / <-30 dBm (>1GHz)
Adjacent Channel Power (Tx)>60 dB @ 12.5 kHz / >70 dB @ 25 kHz
FM Hum and Noise (Tx)-40 dB @ 12.5 kHz / -45 dB @ 25 kHz
Audio Response (Tx)+1 to -3 dB
Audio Distortion (Tx)3% typical
Receiver Sensitivity (Analog)0.16 μV typical (12 dB SINAD)
Receiver Sensitivity (Digital)0.14 μV typical (5% BER)
Adjacent Channel Selectivity (Rx)>60 dB @ 12.5 kHz / >70 dB @ 25 kHz
Intermodulation (Rx)>70 dB
Spurious Rejection (Rx)>70 dB
Audio Output Power (Rated)1W
Audio Output Power (Max)3W
Maximum Speech Loudness106 phons (ISO 532B)
USB PortUSB-C for charging and programming
Audio ConnectorSlim GCAI accessory port
Signalling5-tone signalling supported
Voice Operated TransmitVOX hands-free operation supported
Canned Text MessagingSend only (NKP variant)
Over-the-Air ProgrammingVia DMR supported
Secure ProcessorEnhanced security architecture
