Walkie Talkies

Motorola R7a

MOTOTRBO R7a Portable Radio (No Keypad)

Contact for Price

Minimum Order Quantity:1 unit

The Motorola R7a is a rugged no-keypad portable radio delivering game-changing audio capabilities and dependable communication. Featuring a 2.4" QVGA display, AI-trained noise suppression, and dual-band Wi-Fi connectivity, the R7a ensures crystal-clear communications in the toughest environments. With IP68 waterproof rating, MIL-STD-810H durability, and up to 28 hours of battery life, this radio is built for mission-critical operations across public safety, industrial, and commercial sectors.

IP68 Rated (2m/2hrs)

IP66 Rated (water jet)

MIL-STD-810 C/D/E/F/G/H

TIA4950 Hazloc Certified

ETSI DMR Tier II/III Compliant

FCC Certified

IC Certified

Maritime Certified (VHF models)

WPA3 Wi-Fi Security

Bluetooth 5.2 Certified

Download Datasheet (PDF)

Key Features

Superior Audio Intelligence

AI-trained noise suppression automatically filters background noise. Automatic acoustic feedback suppression eliminates whistling. Intelligent audio adjusts volume based on ambient noise levels for optimal clarity.

Rugged & Reliable

IP68 waterproof (submersible 2m/2hrs) and IP66 water jet resistant. MIL-STD-810H tested for extreme conditions. Disinfectant-resistant housing for demanding environments.

Advanced Connectivity

Dual-band Wi-Fi 2.4/5.0 GHz with WPA3 security. Bluetooth 5.2 for wireless accessories and data transfer. GNSS support for GPS, GLONASS, BEIDOU, and GALILEO positioning.

Extended Battery Life

Up to 28 hours of operation with 3200mAh battery. IMPRES technology optimizes battery performance and charging cycles. Hot-swappable battery design for continuous operation.

Technical Specifications

ModelR7a (No Keypad)

Frequency RangeVHF: 136-174 MHz / UHF: 400-527 MHz / 800/900 MHz: 806-825, 851-870, 896-902, 935-941 MHz

Channel Capacity64 channels

DisplayN/A (No Keypad Model)

High Power OutputVHF: 5W / UHF: 4W / 800/900: 2.5W

Low Power Output1W (all bands)

Channel Spacing12.5 kHz / 20 kHz / 25 kHz

Operating Voltage7.5V (nominal)

Dimensions (H×W×D)131.8 x 56 x 31.3mm (5.2 x 2.2 x 1.2 in.) without belt clip

Weight (with 2200mAh battery)289g (10 oz)

Weight (with 2850mAh battery)306g (11 oz)

Weight (with 3200mAh battery)339g (12 oz)

Battery Life (2200mAh)Digital: 20hrs / Analog: 15hrs (VHF)

Battery Life (2850mAh)Digital: 26hrs / Analog: 19.5hrs (VHF)

Battery Life (3200mAh)Digital: 29hrs / Analog: 22hrs (VHF)

Operating Temperature-20°C to +60°C (-4°F to +140°F)

Storage Temperature-40°C to +85°C (-40°F to +185°F)

Water IntrusionIP68 (2m/2hrs submersion) / IP66 (high-pressure water jets)

ESD ProtectionIEC 61000-4-2 Level 4

HumidityPer MIL-STD-810

Salt Fog Resistance5% NaCl for 8hrs at 35°C

FM Modulation12.5 kHz: 11K0F3E / 25 kHz: 16K0F3E

Digital Modulation4FSK: 7K60F1D & 7K60FXD (data only)

Digital ProtocolETSI TS 102 361-1,-2,-3,-4 DMR Tier II and DMR Tier III

Conducted/Radiated Emissions<-36 dBm (<1 GHz) / <-30 dBm (>1 GHz)

Adjacent Channel Power60 dB @ 12.5 kHz / 70 dB @ 20/25 kHz

Frequency Stability±0.5 ppm

Modulation Limiting±2.5 kHz @ 12.5 kHz / ±4.0 kHz @ 20 kHz / ±5.0 kHz @ 25 kHz

Analog Sensitivity0.16 μV (0.21μV for 800/900 MHz) @ 12 dB SINAD

Digital Sensitivity0.14 μV (0.18μV for 800/900 MHz) @ 5% BER

Intermodulation (Rx)70 dB

Adjacent Channel Selectivity>60 dB @ 12.5 kHz / >70 dB @ 20/25 kHz

Spurious Rejection (Rx)70 dB

Audio Output Power (Rated)1W

Audio Output Power (Max)3W

Maximum Speech Loudness102 phon default / 107 phon programmable @ 30 cm

Wi-Fi StandardsWi-Fi 5 / IEEE 802.11a/b/g/n/ac

Wi-Fi Frequency2.4 GHz / 5.0 GHz

Wi-Fi SecurityWPA-3, WPA-2

Bluetooth VersionBluetooth Core 5.2 (Dual Mode)

Bluetooth RangeClass 2, 10m (33 ft)

GNSS ConstellationsGPS, GLONASS, BEIDOU, GALILEO

GNSS Accuracy<5 meters horizontal

Time To First Fix (Cold)≤60 seconds

Time To First Fix (Hot)≤10 seconds

FCC IDAZ489FT7144 (VHF) / AZ489FT7143 (UHF) / AZ489FT7169 (800/900)

IC ID109U-89FT7144 (VHF) / 109U-89FT7143 (UHF) / 109U-89FT7169 (800/900)
