Motorola APX 900
Walkie Talkies

Motorola APX 900

APX Two-Way Radio Full Keypad

Contact for Price
Minimum Order Quantity:1 unit

The Motorola APX 900 is a mission-critical P25 two-way radio designed for public safety and professional users who demand reliable, secure communications. Featuring dual-band operation, integrated GPS/GLONASS, Bluetooth 4.0 LE connectivity, and advanced encryption capabilities including AES-256, the APX 900 delivers superior performance in the most demanding environments. With IP68 waterproof rating, MIL-STD-810 durability, and intelligent audio features, this radio ensures clear communication when it matters most.

IP68 Rated (2m/2hrs)
MIL-STD-810 C/D/E/F/G
FIPS 140-3 Level 1
FIPS 197 Compliant
FCC Certified
Industry Canada Certified
P25 CAI Compliant
ASTRO 25 Compatible
Download Datasheet (PDF)

Key Features

P25 Trunking & Conventional

ASTRO 25 trunked and conventional operation with analog MDC-1200 and digital P25 signaling. Supports narrow and wide bandwidth configurations (6.25kHz equivalent/12.5kHz/25kHz) for flexible deployment.

Advanced Security

Single-key ADP encryption standard, optional AES-256-bit software encryption with 48 encryption keys. FIPS 140-3 Level 1 certified for government and public safety applications.

Precise Location Tracking

Integrated GPS/GLONASS for accurate outdoor location tracking (<10m accuracy). Autonomous non-assisted GPS mode with cold start <60s and hot start <5s for rapid positioning.

Rugged & Reliable

IP68 waterproof (submersible 2m/2hrs). Meets MIL-STD-810 C/D/E/F/G standards for extreme conditions. Operating temperature -30°C to +60°C for all-weather reliability.

Technical Specifications

ModelAPX 900 (Full Keypad)
Frequency BandsVHF: 136-174 MHz / UHF R1: 380-480 MHz / UHF R2: 450-520 MHz / 700/800 MHz / 900 MHz: 896-902, 935-940 MHz
Channel Capacity512 channels
DisplayFull bitmap color LCD, 3 lines of text x 14 characters, 1 line of icons, white backlight
RF Output Power (Adjustable)VHF/UHF: 1-5W / 700/800 MHz: 1-2.5W (700), 1-3W (800) / 900 MHz: 1-2.5W
Channel Spacing12.5/20/25 kHz (all bands)
Modulation Limiting±2.5/4/5 kHz @ 12.5/20/25 kHz
Frequency Stability (-30°C to +85°C)±1.0 ppm
Audio Response+1/-3 dB
FM Hum & Noise-45/-47 dB @ 12.5/25 kHz
Audio Distortion1.00%
Emissions (Conducted & Radiated)-75 dBc
Receiver Audio Output Power500 mW
Analog Sensitivity (12 dB SINAD)0.216 µV (VHF) / 0.234 µV (UHF) / 0.250 µV (700/800) / 0.237 µV (900)
Digital Sensitivity (5% BER)0.188 µV (VHF) / 0.207 µV (UHF) / 0.250 µV (700/800) / 0.224 µV (900)
Selectivity (12.5/25 kHz)-70/-76 dB (VHF) / -67/-76 dB (UHF/700/800) / -67 dB (900)
Intermodulation79.5 dB (VHF) / 77.0 dB (UHF) / 75.0 dB (700/800/900)
Spurious Rejection-79.3 dB (VHF) / -80.3 dB (UHF) / -76.6 dB (700/800) / -76.0 dB (900)
Dimensions (with STD battery)5.1 x 2.2 x 1.4 in (130 x 55 x 36 mm)
Dimensions (with HI-CAP battery)5.1 x 2.2 x 1.6 in (130 x 55 x 41 mm)
Weight (with STD 2100mAh battery)11 oz (315 g)
Weight (with HI-CAP 3000mAh battery)12 oz (347 g)
Battery (Standard)IMPRES Li-Ion 2100 mAh, slim high density, IP68 (PMNN4491B)
Battery (Optional Hi-Cap)IMPRES Li-Ion 3000 mAh (PMNN4493A) / 2900 mAh UL-rated (PMNN4489A)
Operating Temperature-30°C to +60°C
Storage Temperature-40°C to +85°C
Water & Dust IntrusionIP68 (2 meters, 2 hours)
ESD ProtectionIEC 61000-4-2
HumidityPer MIL-STD
Bluetooth VersionBluetooth 4.0 LE (Low Energy)
Bluetooth EncryptionSSP Pairing, 128-bit AES-CDM for voice/data/signaling
Bluetooth ConnectionsUp to 6 data + 1 audio
GNSS ConstellationsGPS and GLONASS
GNSS Tracking Sensitivity-154 dBm
GNSS Accuracy<10 meters (95%, >5 satellites visible)
GNSS Cold/Hot Start<60s / <5s (95%)
Encryption AlgorithmsADP (standard), AES 256-bit (optional)
Encryption Keys per Radio48 keys
Encryption StandardsFIPS 140-3 Level 1, FIPS 197
Key ErasureKeyboard command
FCC ID (VHF)AZ489FT7098
FCC ID (UHF R1)AZ489FT7097
FCC ID (UHF R2)AZ489FT7099
FCC ID (700/800)AZ489FT7096
FCC ID (900)AZ489FT7100
Industry Canada (VHF)109U-89FT7098
Industry Canada (UHF R1)109U-89FT7097
Industry Canada (UHF R2)109U-89FT7099
Industry Canada (700/800)109U-89FT7096
Industry Canada (900)109U-89FT7100
FCC Emission Designators11K0F3E, 16K0F3E, 8K10F1D, 8K10F1E, 8K10F1W
KeypadBacklit keypad, 2 soft keys, 4-direction navigation key, Home and Back buttons
Buttons & SwitchesPTT button, Two-knob (volume + channel/talkgroup), Orange emergency button, 3 programmable side buttons
FLASHport Memory2 GB
Programming SoftwareWindows 7/8/10 CPS with Radio Management
Optional FeaturesAES-256 Encryption, Enhanced Data, Enhanced Noise Suppressor, Multi-Key, OTAP, RFID Volume Knob, Mission Critical Geofence, P25 Authentication, Digital Tone Signaling, UL-certified
