Walkie Talkies

Motorola APX 8000XE

APX P25 Multiband Portable Radio (Intrinsically Safe)

Contact for Price

Minimum Order Quantity:1 unit

The Motorola APX 8000XE is the industry's first quad-band portable P25 radio with intrinsically safe certification, delivering unmatched interoperability across VHF, UHF1, UHF2, and 700/800 MHz bands in a single device. With P25 Phase 2 TDMA technology, IP68 waterproof rating, ATEX/IECEx certification for hazardous locations, and advanced AES-256 encryption, the APX 8000XE provides mission-critical communications for oil & gas, chemical processing, mining, and other hazardous environment operations. The distinctive lime green housing ensures high visibility in low-light conditions.

IP68 Rated (2m submersion for 2 hours)

MIL-STD-810 C/D/E/F/G Certified

ATEX Zone 0/1/2 Certified (II 1G Ex ia IIC T4 Ga)

IECEx Certified (Ex ia IIC T4 Ga)

UL/cUL HazLoc Listed (Class I, II, III Division 1)

FIPS 140-2 Level 3

FIPS 197 Compliant

FCC Certified

IC Certified

P25 CAI Compliant

ASTRO 25 Compatible

CE Marked

Download Datasheet (PDF)

Key Features

Quad-Band Interoperability

One radio covers four frequency bands: VHF (136-174 MHz), UHF1 (300-400 MHz), UHF2 (400-520 MHz), and 700/800 MHz (764-870 MHz). Eliminates need to carry multiple radios for cross-band operations in hazardous locations. Flexible all-band antenna optimizes performance across all frequencies.

P25 Phase 2 TDMA

Dual-slot TDMA technology doubles voice capacity within 12.5 kHz bandwidth. Backward compatible with P25 Phase 1 FDMA and analog systems. Provides clear digital audio with extended battery life compared to analog operation.

Intrinsically Safe Certified

ATEX Zone 0/1/2 and IECEx certified for use in explosive atmospheres. UL/cUL HazLoc certified for Class I, II, III Division 1 environments. Safe for oil & gas refineries, chemical plants, grain handling, and mining operations where flammable gases, vapors, or dust are present.

IP68 Waterproof Rating

Submersible to 2 meters underwater for up to 2 hours. Exceeds IP67 standards for water immersion. Fully sealed construction protects against dust, sand, and harsh environmental conditions. Ideal for marine, firefighting, and extreme weather operations.

Mission-Critical Security

Hardware-based 256-bit AES encryption with FIPS 140-2 Level 3 certification. Optional DES, DES-XL, DES-OFB algorithms. Secure key storage with tamper detection. Over-the-Air Rekeying (OTAR) capability for remote key management.

High-Visibility Design

Distinctive lime green housing ensures maximum visibility in low-light, smoke-filled, or emergency conditions. Ergonomic design with large buttons for easy operation with gloves. Integrated GPS/GLONASS for accurate personnel tracking and location awareness.

Technical Specifications

Product SeriesMotorola APX 8000XE P25 Multiband Portable Radio (Intrinsically Safe)

Model NumberH91TGD9PW7AN

Frequency RangeVHF: 136-174 MHz | UHF1: 300-400 MHz | UHF2: 400-520 MHz | 700/800 MHz: 764-870 MHz

Operating ModeP25 Phase 1 FDMA / Phase 2 TDMA

Channel Capacity3000 channels

Channel Spacing25/12.5 kHz (analog) | 12.5 kHz (digital)

RF Output Power (VHF)1-5W (adjustable)

RF Output Power (UHF1/UHF2)1-5W (adjustable)

RF Output Power (700/800 MHz)1-3W (adjustable)

Modulation TypeC4FM (digital), 4FSK, 16K0F3E (analog)

Digital ProtocolAPCO P25 Phase 1 FDMA / Phase 2 TDMA, 9600 Baud

Analog ConventionalMDC-1200, Quik Call II, PL/DPL

Digital ConventionalAPCO P25, ASTRO 25

Trunking StandardsSmartZone, SmartZone Omnilink, SmartNet

Frequency Stability (-30°C to +60°C)±0.0002%

Emissions (Conducted)-75/-85 dBc

Audio Response+1, -3 dB (EIA)

FM Hum & Noise (25 kHz)-50 to -53 dB

FM Hum & Noise (12.5 kHz)-48 to -52 dB

Audio Distortion2% @ rated power

Receiver Sensitivity (Analog)-120 dBm (12 dB SINAD)

Receiver Sensitivity (Digital)-120 dBm (5% BER)

Selectivity (25 kHz)85 dB

Selectivity (12.5 kHz)75 dB

Intermodulation (25 kHz)82-86 dB

Intermodulation (12.5 kHz)82-85 dB

Spurious Rejection91-95 dB

Audio Output Power2W at 3% distortion

DisplayColor LCD with backlight | 178° viewing angle | Automatic brightness adjustment

KeypadFull alphanumeric keypad | Tactile feedback | Backlit keys for night operation

Programmable ButtonsUp to 16 programmable buttons for quick function access

GPS Channels12 channels (GPS/GLONASS)

GPS Tracking Sensitivity-153 dBm

GPS Accuracy<10 meters (95%)

GPS Cold Start<60 seconds (95%)

GPS Hot Start<10 seconds (95%)

GPS ModeAutonomous (Non-Assisted) GPS

Encryption AlgorithmsADP / 256-bit AES / DES / DES-XL / DES-OFB / DVP-XL

Encryption Capacity8 algorithms

Encryption Keys per RadioModule capable of storing 1024 keys (64 CKR or 16 PID)

Encryption StandardsFIPS 140-2 Level 3, FIPS 197

Key StorageTamper protected volatile or non-volatile memory

Key ErasureKeyboard command and tamper detection

Digital ID Capacity10,000,000 Conventional / 48,000 Trunking

Network Access Codes4,096 network site addresses

User Group Addresses65,000 Conventional / 4,094 Trunking (P25 CAI)

Signaling Rate9.6 kbps

Error CorrectionGolay, BCH, Reed-Solomon codes

Battery TypeRechargeable Li-Ion IMPRES 2 (Intrinsically Safe)

Battery Capacity2200 mAh (IS standard) | 3000 mAh (IS extended)

Standby Time (2200 mAh)Up to 14 hours (5/5/90 duty cycle)

Talk Time (2200 mAh)Up to 11 hours (5/5/90 duty cycle)

Charging Time<3 hours (rapid charger)

Dimensions (with standard battery)6.1 x 2.4 x 1.6 in (155 x 61 x 41 mm)

Weight (with standard battery)Approx. 1.4 lbs (635 g)

Operating Temperature-30°C to +60°C

Storage Temperature-40°C to +85°C

Water & Dust ProtectionIP68 (submersible to 2m for 2 hours)

Military StandardMIL-STD-810 C/D/E/F/G (Low Pressure, High/Low Temperature, Temperature Shock, Solar Radiation, Rain, Humidity, Salt Fog, Blowing Dust/Sand, Vibration, Shock, Immersion)

FLASHport MemoryBuilt-in support

Programming SoftwareWindows Customer Programming Software (CPS)

USB CommunicationsSupported via accessory connector

BluetoothBluetooth 4.0 LE for wireless accessories

Wi-Fi802.11 b/g/n for firmware updates and programming

NFCNear Field Communication for intelligent accessories

Man-Down AlertAutomatic alert if radio remains motionless for preset duration

Lone WorkerPeriodic check-in reminders with escalation if no response

Emergency ButtonDedicated orange emergency button (programmable)

Text MessagingPredefined and free-form text messaging

Antenna ConnectorTNC female

Accessory Connector16-pin circular connector

Hazardous Location CertificationATEX II 1G Ex ia IIC T4 Ga | IECEx Ex ia IIC T4 Ga | UL/cUL Class I Div 1 Groups A,B,C,D | Class II Div 1 Groups E,F,G | Class III

Warranty1 year manufacturer warranty
